Mori Seiki SL-25
Supplier of Cnc Lathe Machine
Importers of CNC Turning Center
Dealers of Vertical Machining Center
Supplier Cylindrical Grinding Machine
Dealer of Used Cnc Lathe Machine
- Max Turning Diameter: 340 mm (13.4 inches)
- Max Turning Length: 520 mm (20.5 inches)
- Swing Over Bed: 520 mm (20.5 inches)
- Distance Between Centers: 625 mm (24.6 inches)
- Machine Weight: Approx. 5,500 kg to 6,000 kg (12,000 lbs to 13,000 lbs)
- Spindle Speed: 35 to 3,500 RPM
- Spindle Bore: 78 mm to 80 mm (approx. 3.0 to 3.1 inches)
- Spindle Nose: A2-6
- Spindle Motor: 11/15 kW (15 HP to 20 HP)
- Turret Stations: 10
- X-Axis Travel: 160 mm
- Z-Axis Travel: 590 mm to 1090 mm
- Guideways: Heavy-duty box ways
- Quill Diameter: 110 mm (4.33 inches)
- Quill Taper: MT-4
- Quill Stroke: 100 mm
